Our DIY set for building your own composting toilet, including toilet seat with lid, urine diverter in grey or white, solids container (11l or 22l) and liquids container (10l).
Description
- DIY set for building your own composting toilet
- Allows easy disposal of toilet waste
- High-quality toilet seat with lid
- Durable urine diverter including replaceable adapter system with filter sieve
- Air- and liquid-tight sealable containers
- Easy transport of the containers thanks to carrying handles
- Easy and hygienic cleaning
- Material urine diverter: polypropylene, 100% recyclable
Dimensions & weight
Dimension toilet seat with lid in mm:
Height 55 | Depth 404 | Width 330
Dimensions composting toilet insert in mm:
Height 170 | Depth 375 | Width 322
Inner diameter composting toilet insert in mm:
Longitudinal 310 | Transverse 240
Dimensions liquids container (4.6l) in mm:
Length 163 | Width 260 | Height 156
Dimensions liquids container (10l) in mm:
Length 280 | Width 170 | Height 280
Dimensions solids container (6.5l) in mm:
Length 303 | Width 165 | Height 252
Dimensions solids container (11l) in mm:
Ø Top 270 | Ø Bottom 228 | Height 263.2
Dimensions solids container (22l) in mm:
Ø Top 319 | Ø Bottom 285 | Height 316
Scope of delivery
1xtoilet seat (wooden) with lid
1xcomposting toilet insert
1xcutting template
1xfilter sieve and hose connection with integrated filter sievefor DN 32
1xliquids container (4.6l or 10l)
1xsolids container (6.5l, 11l or 22l)
1xassembly instructions diverter
1xinstructions for care and maintenance diverter
Downloads
Also available as a complete kit
If you want to build your own composting toilet but prefer to buy the material for your toilet body from us rather than a hardware store, we recommend our TROBOLO TeraBlœm complete kit. The kit can be assembled and put into operation in no time at all and without any additional tools.
Custom planning with our DIY sets
You can plan and equip your DIY composting toilet with a 6.5l, 11l or 22l solids container as required.
For a 15 mm thick toilet body, for example, the external dimensions are 395 x 340 x 341 mm when using the 6.5l solids container or 480 x 320 x 462 mm for the 11l solids container and 525 x 380 x 462 mm (DxWxH) for the 22l solids container.
For the internal dimensions of your composting toilet, you should calculate with at least 365 x 310 x 308 mm for the 6.5l solids container or 450 x 290 x 429 mm for the 11l solids container and 495 x 350 x 429 mm (DxWxH) for the 22l solids container.
Important note: To ensure that your toilet body is compatible with our toilet seats when using the 6.5l solids container, you should choose slightly larger external dimensions.
Specifically, the external dimensions should be at least 450x340x341 mm when using the wooden toilet seat.
Would you like to build your own composting toilet?
Here you will find useful tips on how to build your own composting toilet, including detailed instructions.
